M20 residential yacht

Antrieb

draught

fuselage shape

CE category

Welcome to a new world of residential yachts

Relaxing at home or at work
In the comfortable Wohnyacht Experience a new way of life.

Living Spaces on the Water

This model is one of the most innovative and sustainable “mobility and living concepts”, that are currently on the market. As a modern symbiosis between Penthouse and residential yacht, this model has its own fascination.

The aim is to create “sustainable and intelligent living space” on the water that you can use for both private and commercial purposes (holiday home & floating office).

High-quality steel construction
Sustainable and stable in value
Safe — bow and stern thrusters, pole anchors
Autonomous — own waste and inflow water treatment
Ecological — solar or diesel hybrid drive
Modular (freely selectable layout, apartment, office, event location)
Full basement — sleeping cabins and storage spaces
Profitable as a floating holiday home or office

This model is the ideal travel ship and full-fledged sports boat for all slow-flowing rivers (Moselle, Main, Danube, Berlin waters and French canals). Imagine discovering the most beautiful wine regions and cultural landscapes in Europe with your mobile phone. With the push of a button, you can easily and safely maneuver your home to the berth using the bow stern thruster, and just as easy is the push of a button to extend your telescopic anchor (pole anchor) and securely anchor the ship. So you can on “your little private island” enjoy the most beautiful views in peace.

Do you have a special dream where you would like to live and travel? For example, for the narrower French waterways, the ship width can be adjusted to 4.00 or 4.50 meters; the railings of the deck lounge can be folded so that you can discover the most beautiful places in France.

But the inner values are also tough. On request, the mobile is equipped with a quiet and environmentally friendly John Deere marine diesel engine or a hybrid drive equipped. The ship is ideal for permanent living on board, as the entire living room has a complete basement and can be accessed via two hatches with stairs. All sections can be equipped with radiators so that your supplies, clothing boxes, etc. remain dry even on cold winter days.

You can your Wohnyacht Have it built in the following lengths and widths

12 meters x 4.00 or 4.50
Living space of 40 to 50 sq m — living space over 100 sq m
12 meters x 5.00 or 5.50
Living space of 40 to 60 sq m — living space over 100 sq m
15 meters x 4.00 or 5.50
Living space of 50 to 60 sq m — living space over 120 sq m
20 meters x 4.50 or 5.50
Living space from 80 to 100 sq m — living space over 150 sq m

All sqm2 sizes are approximate dimensions and depend on individual planning.

Plug & Play, or would you prefer a turnkey residential yacht?

Do you have precise ideas and design preferences that you would like to incorporate into your boat? Would you like to save money and do various installations yourself?

No problem As”Plug & Play solution“You will be offered the perfect installation of your bathroom and kitchen furniture. Together with the yacht architect, you plan the bathroom, specify the position of connections, sockets, outlets, etc., and it is built with millimetre precision so that you can enjoy your dream furniture on the water. Design your second life according to your wishes. We advise you individual and comprehensive, from planning to financing.

CE Category D — Protected Waters

Designed for trips in protected coastal waters, small bays, on small lakes, narrow rivers and canals, where weather conditions with wind speeds of up to and including 4 and significant wave heights of up to 0.3 m and occasionally wave heights of not more than 0.5 m, for example due to passing ships.

Are you looking for a mooring?

One of the unique advantages of this home is that they are fully-fledged and safe travel vessels that are also registered as sports boats. Because of this special position, you can moor in any port with a ship like this, just like a yacht.

Perfectly equipped for your self-sufficient life waterborne

Basic equipment/fuselage

6 mm steel hull, epoxy coated with 25 year warranty
5 mm steel structures insulated from the inside
Double glazed aluminum windows in the desired color
Hull foamed up to the waterline and insulated
Deck covering painted in desired color with anti-slip coating
4 solid stainless steel bollards and 4 stainless steel cleats
All-round stainless steel railing at the bottom
Small stainless steel railing on top of deck lounge (foldable on request)
stainless steel stairs to deck lounge
stainless steel steering position with John Deere panel (tachometer, temperature, etc.)
25 kg Poole Anchor
Special Equipment: GPS, plotter, echo sounder, autopilot, anchor winch
Aluminum deck hatches front and rear with stainless steel stairs to the basement
LED all-round lighting outside

Basic equipment/on-board technology

107 hp — 4 cylinder John Deere marine diesel
ZF transmission and oil-lubricated shaft system
1000 liter water tank
1000 liter heating oil tank
1000 liter diesel tank
1500 liter waste tank (conventional via suction)
Kabola — HR 500 oil central heating (with WLAN remote control)
radiators in the upper aisle (living room, bathroom, bedroom)
2 radiators in the cellar
Central board panel
battery pack
All rooms are equipped with GIRA sockets
16 amp shore connection with VICTRON converter

Basic equipment/interiors

Ceilings with stretch ceiling and LED lighting
Walls coated with wood design panels
Plastic parquet flooring (real parquet on request)

Basic equipment/mini kitchen

washbasin,
electric stove, exhaust hood,
refrigerator,
base cabinet
On request, your brand kitchen can be installed

Basic equipment/bathroom

washbasin,
shower,
toilet,
Grohe faucets

special equipment
For your life on the water, with and without marine infrastructure, you need your own concept. On request, these models can be equipped with the following equipment.

Biological faecal sewage treatment plant (clear, treated water is discharged into the body of water)
Drinking water disinfection and revitalization, boosting health on board
Solar panels or wind turbines create new energy resources
Lithium ion power storage modules, fill up with power and have them at any time
Wood pellet heating, use renewable raw materials
Heat pump, generate energy sustainably
Generator, the power source for emergencies
GPS, autopilot and chart plotter, your GPS on the water
air conditioning and sunshades
Foldable or hydraulic swim platform
hydraulic deck crane with dinghy
parquet flooring
floor heating
woodburning stove
telescopic anchor

Yacht benefits

With timeless design, exceptional technology and a previously unparalleled sense of space, the new models inspire with an unforgettable lifestyle. That is unique.

Instead of neighbors and gardens, Light-flooded rooms with a direct view of the water
Open doors, bring in furniture. Set it up just the way you like
The Sky Deck Lounge, relax and enjoy in the open air
Stable and solid, up to 2 tons ceiling load, ideal for a deck crane and dinghy
Heavy Duty John Deere marine diesel up to 20 km fast
Like at home heated cellar, storage and engine room
A good feeling the 25-year warranty on the hull
The perfect retirement base, can be rented out profitably as floating living space at any time
manageable, the construction period of 6 months
25 year warranty on the fuselage, a property for generations

Design Your second life according to your wishes. We advise you individual and comprehensive, from planning to financing.

conventional yachts and houseboats are designed as series products for leisure purposes in such a way that you “subject to rapid loss of value due to design”. This model is based on a new philosophy: “Building and creating sustainable value”. Designed and built like a tailor-made real house, invest in so-called furniture, which guarantees you an attractive additional income for decades, depending on the location. There are lots of new things to discover, read more.

10 unique residential yacht benefits

1. Sustainable generational product

Live carefree. Thanks to a durable and solid steel construction, we offer you a 25-year warranty on the hull. That is unique.

2. Safety, whatever the weather

Thanks to a high-quality and solid construction combined with a solid rod anchor, even extreme environmental influences cannot harm. Reassuring

3. Clean, renewable energy

Equipped with solar panels, you can enjoy the convenience of powering yourself independently. Excess energy produced, simply feed it profitably into the grid. Simply clever.

4. Living autonomously and ecologically

Regardless of any marina infrastructure, you can produce your own drinking water on request, or even treat 100% harmless waste water and discharge it cleanly. It's a good feeling to be at peace with the environment.

5. Healthy and pleasant indoor climate

Thanks to a steel structure and ecological insulation materials, you can enjoy an indoor climate without harmful foreign odors.

6. Intact ecological environment

Sustainable and ecologically sound technologies, such as ultrasonic algae protection or a biological sewage treatment plant, protect the environment. It's a good feeling.

7. Modular technical upgrade at any time

Each Wohnyacht is designed in such a way that you can have new future technologies, such as (Li-ion storage, solar, fuel cell, hybrid... etc.), installed at any time. Maintaining value that makes you happy.

8. Anytime, spatially changeable

Due to the modular construction (steel body with flexible partitions), you can have your residential yacht converted for new purposes at any time, whether as a floating office, holiday apartment, showroom or event location.
Flexibility is key.

9. Your houseboat as a retirement plan

As an innovative “furniture”, your Wohnyacht the unbeatable advantage of a lucrative holiday home in attractive locations all over the world. Earn money and share the joy of a unique lifestyle. Simply clever.

10. 360 degree service

We offer you a comprehensive 48-hour Europe-wide service for peace of mind.

‍

funding

In the past, houseboat financing was difficult because, in contrast to construction financing, it did not offer a land register entry as collateral. However, the situation has improved steadily in recent years, not least due to growing demand. Through our partner comparison portal, you can now discover suitable offers at attractive conditions.

Compare now

length

width

Passage height

Usable area

Remodeled space

prize
